Buy Software Companions GerbView 10 Global Software License

How to activate:

• Download and install the software HERE.
• Activate the received key.

GerbView is an advanced but easy-to-use application that enables you to view, print and convert Gerber, ODB++, Adobe PDF, Excellon, HPGL/2 and other formats.

GerbView supports both RS-274D and RS-274X Gerber formats, and you can use it to convert your older Gerber files to the new RS-274X extended format. The new extended Gerber format contains embedded aperture information and using this format will minimize the risk for errors during the manufacturing of the PCB.

With GerbView's PDF to CAD capability you can convert your Adobe PDF files to Gerber or Autodesk DXF.

Gerbview will visualize your design, on the screen or in hardcopy. You no longer have to wait for a prototype circuit board to see your true design. Use the accurate measure and query tools to check apertures, tools, distances and more.

In GerbView you work with a workspace that can contain one or more files of the supported file formats. The workspace can be saved for later use. The saved workspace will link to your design files, so only need to reload the workspace file to see the whole design.

Features:

• View, print, markup and convert Gerber, Adobe PDF, Excellon, ODB++ and HPGL/2 (PLT).
• Convert your Gerber, Excellon, ODB++ and HPGL/2 files to Autodesk DXF, Adobe PDF and other formats.
• Convert from RS-274D to RS-274X, known as extended Gerber format.
• Convert your PDF files to Gerber RS-274X, HPGL/2 or DXF.
• Convert multiple Gerber files to a multi-layer PDF, DWF or DXF file. Read more about creating layered PDF files here.
• Convert ODB++ to a layered PDF, or to individual files using Extended Gerber (RS274-X), PDF, DXF, SVG or other formats.
• Gerber X2 file and pads attributes are supported.
• Add markups, also know as annotations, using text, images, QR-codes, barcodes, symbols, lines, polygons and other shapes.
• Use the markup burn-in feature to convert markup elements to native Gerber data.
• Compare Gerber layers and display differences.
• Delete a selection of items from a loaded Gerber file.
